RoHS Compliant 7 Segment LED Display Common Anode Ultra Bright Easy Assembly

Certification
Good quality 16 Segment LED Display for sales
Good quality 16 Segment LED Display for sales
I'm Online Chat Now

RoHS Compliant 7 Segment LED Display Common Anode Ultra Bright Easy Assembly

China RoHS Compliant 7 Segment LED Display Common Anode Ultra Bright Easy Assembly supplier
RoHS Compliant 7 Segment LED Display Common Anode Ultra Bright Easy Assembly supplier RoHS Compliant 7 Segment LED Display Common Anode Ultra Bright Easy Assembly supplier

Large Image :  RoHS Compliant 7 Segment LED Display Common Anode Ultra Bright Easy Assembly

Product Details:

Place of Origin: SHENZHEN,CHINA
Brand Name: LIGHT-BO
Certification: SGS
Model Number: LB20561IWH1B

Payment & Shipping Terms:

Minimum Order Quantity: 500 PCS
Price: negotiable
Packaging Details: EPE+CARTON
Delivery Time: 5-7 days
Payment Terms: T/T
Supply Ability: 20000pcs/day
Contact Now
Detailed Product Description
Character Height: 14.2mm ( 0.56") Outer Dimensions: 25x19x8mm
Emitting Colour: Ultra White Polarity: Common Anode
Service: Excellent Pre-sale And After Sale Service Usage: Digital Clock Indicators ETC
Application: Home Appliance ,electronic Component,automation,industrial Products



Long Lifetime Ultra White 7 Segment Led Displays 2 Digit For Home Applications



Product Description:



Height: 0.56 inch (14.20mm)

Outer dimensions: 25 x 19 x 8 mm

Polarity: common anode/cathode

Emitting color: ultra bright red, ultra bright blue, yellow green, pure green, pure white, amber and orange

Absolute Maximum Ratings(Ta=25℃)



Parameter Symbol Ratings Unit
Forward Current(per dice) Ipm 20 mA
Reverse Voltage(per dice) Vr 5 V
Power Dissipation(per dice) Pm 80 mW
Operating Temperature Range Topr -40~+85
Storage Temperature Range Tstg -40~+85
Solder Temperature(3 sec) Th 260

Code:W-Ultra Bright White

Parameter Symbol Condition Min Typ Max Unit
Forward Voltage(Per dice) Vf If=20mA 2.8   3.5 V
Reverse Voltage(Per dice) Vr Ir=40uA   5   V
Luminous Intensty(Per dice) Iv If=20mA 100   120 mcd
Chromaticity Coordinates X If=20mA 0.29   0.33 nm
Chromaticity Coordinates Y If=20mA 0.29   0.33 nm
Peak Forward Current(Per dice)1/10 Duty Cycle,0.1ms Pulse Ifp 100 mA
Operating Temperature Range Torp -35℃~+85℃
Storage Temperature Range Tstg -35℃~+85℃
SolderTemperature 1.5mm below seating plane for 3 Seconds at 260℃
Absolute Maximum Rating at Ta=25℃

Product Feature:



High luminous intensity and reliability

Low power requirement

Stable performance

long lifetime

Easy assembly

IC compatible

Meet RoHS Compliant

Excellent design of outer appearance

Strict quality testing before it leave the factory

We have our own production workshop and production facility

We can customize it according to the customer's requirements

RoHS Compliant 7 Segment LED Display Common Anode Ultra Bright Easy Assembly



Product Application:



Widely used in instrument panels ,home appliances,and digital numeric displays ,digital indicators and so on.



We Promise:



1. Your inquiry related to our products or prices will be replied in 24 hours.

2. Experienced staffs to answer all your enquires in fluent English.

3. We are doing the OEM and ODM service for more than 10 years.

4. Protection of your sales area, ideas of design and all your private information.

5. No matter big order or small order , we will provide all the best  quality , best service.

6. Advanced equipments and good materials: ASM machine, good chips and epoxy resin.

7. High brightness and low power consumption .

8. If our products have any problem , we will send free in the next  order if it is our mistake.

Contact Details
Shenzhen Guangzhibao Technology Co., Ltd.

Contact Person: lightbo

Send your inquiry directly to us (0 / 3000)
