Super Bright Green 7 Segment Led Displays 0.56 Inches Single Digit

Super Bright Green 7 Segment Led Displays 0.56 Inches Single Digit

Brand Name:	LIGHT-BO
Model Number:	LB10561BJ1B
MOQ:	1000
Price:	Negotiate
Payment Terms:	T/T,Western Union
Supply Ability:	50000 PCS/Day

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Certification:

ISO9001&RoHS

Application:

Indoor Advertising

Operating Temperature:

-45-80℃

Emitting Color:

Green

Digit Height:

0.5

Oem:

Yes

Outer Dimensions:

12.6*19.0*8.0mm

Polarity:

Common Anode

Life Span:

100000hours

Packaging Details:

EPE+CARTON

Supply Ability:

50000 PCS/Day

Highlight:

Green Single Digit 7 Segment Led Displays

Indoor use 7 segment led displays

0.56 inches 7 segment led displays

Product Description

0.56-Inch (14.2mm) Single-Digit 7-Segment LED Display – Dual Polarity (CC/CA) for Home Appliances & Digital Indicators
Luminous Detail Shot: Clear close-up of a single digit (e.g., "8") in red (standard) with white segments and black surface, showcasing high contrast and no "dark edges"—emphasizing readability.
Dimension Labeled Diagram: Marked 12.6×19.0×8.0mm outer dimensions and 14.2mm (0.56-inch) digit height, visualizing the compact size for space-constrained panels.
Polarity Identification Shot: Clear marking of "CC (Common Cathode)" and "CA (Common Anode)" on the back, reinforcing dual-polarity compatibility.
Application Mockup: Integrated into a home appliance (e.g., microwave power level "5"), instrument panel (e.g., pressure gauge "3"), or multimedia device (e.g., volume "7") to demonstrate real-world use.
Multi-Color Comparison Shot: Side-by-side display of available colors (red, blue, green, white, amber, orange, yellow) to highlight customization options.

Product Main Image Area

Detail Image

Core Specifications Table

Specification	Details
Display Type	Single-digit 7-segment LED numeric display (0-9, supports decimal point)
Digit Height	0.56 inch (14.2mm) – optimized for 1-2m readability (ideal for small panels)
Outer Dimensions	12.6×19.0×8.0mm – 8mm slim depth, fits compact appliance/instrument enclosures
Polarity	Dual-compatible (CC/Common Cathode & CA/Common Anode) – no need to replace for different circuits
Segment/Surface Design	White segments + black surface – anti-glare, high contrast for day/night visibility
Emitting Colors	Standard: Red; Optional: Blue, Green, White, Amber, Orange, Yellow
Electrical Traits	Extremely low current; Low power consumption; Forward voltage: 1.8-2.4V (varies by color)
Compliance	RoHS Directive-compliant – free from restricted substances (lead, mercury)
Compatibility	IC-compatible (works with 74HC595, TM1638, MAX7219, etc.)

Key Selling Points
1. Dual Polarity (CC/CA) – One Display, Multiple Circuits
No polarity mismatch: Unlike single-polarity displays that require separate CC/CA versions, this model works with both common cathode and common anode driver circuits. Ideal for manufacturers producing multiple device lines – eliminates the need to stock two display types, reducing inventory costs and assembly errors.
Seamless circuit integration: Compatible with all mainstream 7-segment driver ICs, so no custom voltage inversion or circuit modification is needed. Speeds up R&D for new products and simplifies retrofits for old devices.
2. Compact Size + High Brightness – Perfect for Small Panels
12.6×19.0×8.0mm ultra-compact design: Fits into tight spaces where multi-digit displays can’t – e.g., microwave power level buttons, instrument panel auxiliary indicators, or multimedia device volume controls. The 8mm slim depth ensures it doesn’t protrude from the panel, maintaining a sleek device appearance.
High luminous intensity: Even in the small form factor, the display delivers bright, consistent light – cuts through ambient glare and remains visible in dim environments. Critical for "at-a-glance" readouts.
3. Low Cost & Energy Efficiency – Ideal for Mass Production
Low development + production cost: Standardized design and compatibility with existing manufacturing lines reduce R&D expenses. The single-digit layout is simpler to produce than multi-digit displays, lowering unit costs – perfect for high-volume products.
Extremely low current + low power: Minimizes energy draw, extending battery life for portable devices and reducing long-term electricity use for 24/7 operated equipment. Aligns with eco-friendly product trends and energy-saving certifications.
4. Durable Build & Long Lifespan – Reliable for Daily Use
White segments + black surface: The black matte surface resists scratches from cleaning and reduces reflection, while white segments ensure high contrast with digits. Avoids the "faded segment" issue common in low-quality displays.
Stable performance + long lifespan: Uses high-grade LED chips and yellow epoxy encapsulation (optional) to withstand voltage fluctuations and temperature ranges of -40℃~85℃. Continuous operation lifespan exceeds 50,000 hours – no frequent replacements, even for heavily used devices.

Target Applications
1. Home Appliances
Microwaves/induction cooktops: Power levels, heat settings, or timer minutes/seconds.
Small kitchen appliances: Speed settings or toasting levels.
Smart thermostats: Temperature increments or mode codes.
2. Instruments & Securities Displays
Instrument panels: Auxiliary indicators, battery level, or pressure units.
Securities/interest displays: Single-digit price increments or interest rate indicators.
3. Multimedia & Digital Indicators
Media players/soundbars: Volume levels, input codes, or playback speed.
General digital indicators: Counter digits, error codes, or status

Procurement & Delivery Information

Procurement Item	Details
Minimum Order Quantity (MOQ)	1000 pieces
Unit Price Range	$0.1-$5/piece
Customization Options	Emitting color, decimal point position, pin type
Production Capacity	50,000 pieces/day
Packaging	Anti-static plastic bags + cardboard boxes (shockproof)
Delivery Cycle	In-stock: 2-4 working days; Customized: 5-8 working days
Shipping Methods	Domestic: Express (SF, ZTO); Export: Sea (FOB Shenzhen), Air (DHL/UPS)

Quality Assurance
100% Inspection: Every unit undergoes brightness testing, polarity verification, and RoHS compliance checks before shipment.
Durability Testing: Samples are subjected to 1,000-hour continuous operation tests to ensure no brightness degradation or segment failure.
Warranty: 2-year warranty for non-human damage. If the display fails due to manufacturing defects, free replacement is provided.

Frequently Asked Questions (FAQ)
Q: Does the dual polarity mean I can switch between CC and CA on the same display?
A: Yes – the display is wired to support both polarities, but you must match the driver circuit to one polarity at a time.
Q: Can I add a decimal point to the single digit?
A: Absolutely – decimal points are optional and can be placed on the top, bottom, or side of the digit.
Q: What’s the difference in forward voltage between colors?
A: Red/amber/orange: 1.8-2.2V; Green/blue/white: 2.8-3.2V – we provide color-specific voltage specs to ensure proper circuit design.

Absolute Maximum Ratings(Ta=25ºC)

Parameter	Symbol	Ratings	Unit
Forward Current(per dice)	Ipm	20	mA
Reverse Voltage(per dice)	Vr	5	V
Power Dissipation(per dice)	Pm	80	mW
Operating Temperature Range	Topr	-40~+85	ºC
Storage Temperature Range	Tstg	-40~+85	ºC
Solder Temperature(≤3 seconds)	Th	260	ºC

Code:Yellow Green- J

Parameter	Symbol	Condition	Min	Typ	Max	Unit
Forward Voltage	Vf	If=10mA	1.8		2.4	V
Reverse Voltage	Vr	Ir=10uA	5			V
Luminous Intensty	Iv	If=10mA	30		40	mcd
Spectrum With Of Half Value	△λ	If=10mA		20		nm
Wavelength	Dλ	If=10mA	569		574	nm

Code:Amber/Yellow -Y

Parameter	Symbol	Condition	Min	Typ	Max	Unit
Forward Voltage	Vf	If=10mA	1.8		2.5	V
Reverse Voltage	Vr	Ir=10uA	5			V
Luminous Intensty	Iv	If=10mA	60		80	mcd
Spectrum With Of Half Value	△λ	If=10mA		20		nm
Wavelength	Dλ	If=10mA	585		595	nm

Code:Orange -F

Parameter	Symbol	Condition	Min	Typ	Max	Unit
Forward Voltage	Vf	If=10mA	1.8		2.4	V
Reverse Voltage	Vr	Ir=10uA	5			V
Luminous Intensty	Iv	If=10mA	60		80	mcd
Spectrum With Of Half Value	△λ	If=10mA		20		nm
Wavelength	Dλ	If=10mA	600		605	nm

Code:Super Bright Red -R

Parameter	Symbol	Condition	Min	Typ	Max	Unit
Forward Voltage	Vf	If=10mA	1.8		2.2	V
Reverse Voltage	Vr	Ir=10uA	5			V
Luminous Intensty	Iv	If=10mA	50		60	mcd
Spectrum With Of Half Value	△λ	If=10mA		20		nm
Wavelength	Dλ	If=10mA	630		635	nm

Code:Ultra Bright Red -UR

Parameter	Symbol	Condition	Min	Typ	Max	Unit
Forward Voltage	Vf	If=10mA	1.8		2.2	V
Reverse Voltage	Vr	Ir=10uA	5			V
Luminous Intensty	Iv	If=10mA	80		100	mcd
Spectrum With Of Half Value	△λ	If=10mA		20		nm
Wavelength	Dλ	If=10mA	625		635	nm

Code:Pure Green -G

Parameter	Symbol	Condition	Min	Typ	Max	Unit
Forward Voltage	Vf	If=10mA	2.6		3.2	V
Reverse Voltage	Vr	Ir=10uA	5			V
Luminous Intensty	Iv	If=10mA	120		180	mcd
Spectrum With Of Half Value	△λ	If=10mA		20		nm
Wavelength	Dλ	If=10mA	515		525	nm

Code:Ultra Bright Blue -BH

Parameter	Symbol	Condition	Min	Typ	Max	Unit
Forward Voltage	Vf	If=10mA	2.8		3.2	V
Reverse Voltage	Vr	Ir=10uA	5			V
Luminous Intensty	Iv	If=10mA	120		140	mcd
Spectrum With Of Half Value	△λ	If=10mA		20		nm
Wavelength	Dλ	If=10mA	460		465	nm

Code:Ultra Bright White -WH

Parameter	Symbol	Condition	Min	Typ	Max	Unit
Forward Voltage	Vf	If=10mA	2.8		3.2	V
Reverse Voltage	Vr	Ir=10uA	5			V
Luminous Intensty	Iv	If=10mA	120		140	mcd
LED color Temperature	K	If=10mA	5500	20	6800	K
Chromaticity Coordinates	X/Y	If=10mA	0.29,0.32		0.30,0.33	nm

Shenzhen Guangzhibao Technology Co.Ltd(Brand:Light Bo) stablished in 2006 , A company that integrates R & D, manufacturing and sales of optoelectronics LED Displays . ISO 9001 2015 Quality Management Systems certified company . With more than 15 years OEM and ODM experience .
Light Bo has been committed to provide high quality and low cost customized solutions to help customers reduce cost and enhance competitiveness.

Super Bright Green 7 Segment Led Displays 0.56 Inches Single Digit 4
7 Segment LED Display, Customized LED Display, Numeric LED Display, Dot matrix LED Display, widely used for home appliances,tempearture indicators, humidity indicators, refrigerator controller,thernostats indicator,heating and cooling control and so on.

Super Bright Green 7 Segment Led Displays 0.56 Inches Single Digit 5

Super Bright Green 7 Segment Led Displays 0.56 Inches Single Digit 6

Super Bright Green 7 Segment Led Displays 0.56 Inches Single Digit 7

Super Bright Green 7 Segment Led Displays 0.56 Inches Single Digit 9

Super Bright Green 7 Segment Led Displays 0.56 Inches Single Digit 12

Super Bright Green 7 Segment Led Displays 0.56 Inches Single Digit 13

FAQ(Frequently Asked Questions)
Q1 Are you trading company or manufacturer?
A: We are original manufacturer with more than 20 years experience in optoelectronic LED displays .
Q2 What is your main products?
A: Our main products include 7 Segment LED display, SMD LED Display,Dot matrix LED Display, Arrow LED display, Custom Design LED Display ,LED light bar,Through hole led, SMD LEDs,LED Backlights, and so on.
Q3 What is your MOQ?
A: Our MOQ is 1000 pcs , We can also accept sample orders and small orders with quantity less than our MOQ .
Q4 Before placing order, Can I get some samples for test?
A: Yes. We can provide 5-10 free samples for your testing, but the freight cost will be borne by the customer.
Q5 How long is your delivery time?
A: Delivery time:About 10-20 days; According to order quantity and raw materials. If you have urgent order,and we have raw materials in stock,we can adjust our production plan to make it ready within 7-10 days .
Q6 What is your terms of payment?
A: We accept bank transfer,T/T,Western Union and Paypal with small amount. Detailes of payment methods can be negotiatble.
Q7 Can you quote me FOB prices?
A: Yes. We can quote you prices based on incoterms EXW, FOB, CIF,DDP.
Q8 How can I get your catalogue and price list?
A: Yes . Please let us know your email address or contact us from website directly for our catalogue and price list .
Q9 Can I negotiate the prices?
A: Yes, we may consider discounts for bulk orders.
Q10 How much will the shipping charges be?
A: It depends on the size of your shipment and the method of shipping.
We will offer the charge to you as you requested.
Q11 Can you do custom design products?
A: Yes , OEM&ODM service are available .We can customize the sizes,led color and functional icons according to your requirements.
Q12 If I send my design , can you make it for myself only ,and will not show it to any one else?
A: Yes , we will not show it or sell to others without your authorization.
Q13 What will be the samples lead time for customized products?
A: Samples lead time will be about 20-25 working days after receiving mold cost and mold drawing approval from customers .
Q14 What is the shipping methods?
A:We usually ship the goods by DHL, FEDEX,UPS,EMS,BY AIR,BY SEA etc, also you can choose the other way that best for you.
Q15 How do you ensure the quality of your products?
A: we are ISO 9001 QMS ceritified manufacturers with more than 20 years experience ,We conduct twice 100% percent test for all of our products before shipment.
