Product Description

Discover the versatility of our LED solutions, from dynamic LED displays and high-precision dot-matrix LED displays to reliable LED segment displays—including the popular 7-segment LED displays—all available as ready-to-integrate LED display modules to elevate your projects!

Product Overview

Light-Bo’s customized LED display is engineered specifically for kitchen hoods, combining a slim design (93×16×12mm) with high-performance features to thrive in high-temperature cooking environments. With a 9mm character height and versatile color options (pure green, white, red), it delivers clear visibility for controls and status indicators. Configured as common cathode and featuring a hand motion slider for intuitive operation, this display withstands extreme temperatures (105°C–120°C) while maintaining low power consumption. RoHS/REACH compliant and IC compatible, it’s ideal for kitchen hoods, gas cookers, and multifunction oven timers.



Product Image

Key Features

Extreme Temperature Resistance: Operates reliably in 105°C–120°C environments, making it perfect for kitchen hoods exposed to heat from stoves and ovens.

Hand Motion Slider: Intuitive non-contact control enhances user experience, ideal for busy kitchens where hands may be occupied or messy.

Versatile Color Options: Available in pure green, white, red, with additional choices (blue, amber, orange) to match kitchen hood aesthetics or function coding (e.g., red for high speed, green for low).

Clear Visibility: 9mm character height and a big viewing angle ensure readability from a distance, critical for monitoring fan speeds or timer settings.

Energy Efficiency: Low power consumption minimizes energy usage, suitable for long-term operation in household appliances.

Stable Performance: Good consistency across segments and a long lifespan guarantee reliable operation in daily kitchen use.

Easy Integration: Common cathode configuration and IC compatibility simplify installation into kitchen hood control systems.

Compliant Design: Meets RoHS/REACH standards, ensuring safety for household environments.



Detail Image

Technical Specifications



Applications

Ideal for:

Kitchen hoods (fan speed, timer, or filter cleaning indicators)

Gas cookers and multifunction oven timers

Home appliances requiring heat-resistant, intuitive displays

Cooking control panels in residential or commercial kitchens

Order & Logistics

Minimum Order: 1000 pieces

Trade Term: EXW

Payment Terms: T/T, WU

Origin: Guangdong, China (Mainland)

Transport Options: Ocean, Air, Land

Production Capacity: 20,000 pcs/day

Packing: Plastic Tray (securely protects the display and slider mechanism during transit)

Delivery Time: 10-15 days

SpecificationsSpecifications

• Absolute Maximum Ratings(Ta=25ºC)

  Parameter	Symbol	Ratings	Unit
  Forward Current(per dice)	Ipm	20	mA
  Reverse Voltage(per dice)	Vr	5	V
  Power Dissipation(per dice)	Pm	80	mW
  Operating Temperature Range	Topr	-40~+85	ºC
  Storage Temperature Range	Tstg	-40~+85	ºC
  Solder Temperature(≤3 seconds)	Th	260	ºC



• Code:Yellow Green- J

  Parameter	Symbol	Condition	Min	Typ	Max	Unit
  Forward Voltage	Vf	If=10mA	1.8		2.4	V
  Reverse Voltage	Vr	Ir=10uA	5			V
  Luminous Intensty	Iv	If=10mA	30		40	mcd
  Spectrum With Of Half Value	△λ	If=10mA		20		nm
  Wavelength	Dλ	If=10mA	569		574	nm



• Code:Amber/Yellow -Y

  Parameter	Symbol	Condition	Min	Typ	Max	Unit
  Forward Voltage	Vf	If=10mA	1.8		2.5	V
  Reverse Voltage	Vr	Ir=10uA	5			V
  Luminous Intensty	Iv	If=10mA	60		80	mcd
  Spectrum With Of Half Value	△λ	If=10mA		20		nm
  Wavelength	Dλ	If=10mA	585		595	nm



• Code:Orange -F

  Parameter	Symbol	Condition	Min	Typ	Max	Unit
  Forward Voltage	Vf	If=10mA	1.8		2.4	V
  Reverse Voltage	Vr	Ir=10uA	5			V
  Luminous Intensty	Iv	If=10mA	60		80	mcd
  Spectrum With Of Half Value	△λ	If=10mA		20		nm
  Wavelength	Dλ	If=10mA	600		605	nm



• Code:Super Bright Red -R

  Parameter	Symbol	Condition	Min	Typ	Max	Unit
  Forward Voltage	Vf	If=10mA	1.8		2.2	V
  Reverse Voltage	Vr	Ir=10uA	5			V
  Luminous Intensty	Iv	If=10mA	50		60	mcd
  Spectrum With Of Half Value	△λ	If=10mA		20		nm
  Wavelength	Dλ	If=10mA	630		635	nm



• Code:Ultra Bright Red -UR

  Parameter	Symbol	Condition	Min	Typ	Max	Unit
  Forward Voltage	Vf	If=10mA	1.8		2.2	V
  Reverse Voltage	Vr	Ir=10uA	5			V
  Luminous Intensty	Iv	If=10mA	80		100	mcd
  Spectrum With Of Half Value	△λ	If=10mA		20		nm
  Wavelength	Dλ	If=10mA	625		635	nm



• Code:Pure Green -G

  Parameter	Symbol	Condition	Min	Typ	Max	Unit
  Forward Voltage	Vf	If=10mA	2.6		3.2	V
  Reverse Voltage	Vr	Ir=10uA	5			V
  Luminous Intensty	Iv	If=10mA	120		180	mcd
  Spectrum With Of Half Value	△λ	If=10mA		20		nm
  Wavelength	Dλ	If=10mA	515		525	nm



• Code:Ultra Bright Blue -BH

  Parameter	Symbol	Condition	Min	Typ	Max	Unit
  Forward Voltage	Vf	If=10mA	2.8		3.2	V
  Reverse Voltage	Vr	Ir=10uA	5			V
  Luminous Intensty	Iv	If=10mA	120		140	mcd
  Spectrum With Of Half Value	△λ	If=10mA		20		nm
  Wavelength	Dλ	If=10mA	460		465	nm

•

• Code:Ultra Bright White -WH

• Parameter	Symbol	Condition	Min	Typ	Max	Unit
  Forward Voltage	Vf	If=10mA	2.8		3.2	V
  Reverse Voltage	Vr	Ir=10uA	5			V
  Luminous Intensty	Iv	If=10mA	120		140	mcd
  LED color Temperature	K	If=10mA	5500	20	6800	K
  Chromaticity Coordinates	X/Y	If=10mA	0.29,0.32		0.30,0.33	nm

•
