Numeric LED Display
Created with Pixso.

Four Digit 7 segment Numeric LED Display 0.4 inch pure green for temperature control

name

Four Digit 7 segment Numeric LED Display 0.4 inch pure green for temperature control

Brand Name: LIGHTBO
Model Number: LB40401IG0B
MOQ: 1000PCS
Payment Terms: TT in advance& Western Union
Supply Ability: 50000PCS/Day
Detail Information
Product Description
Detail Information
Place of Origin:
Shenzhen,China
Certification:
RoHS&SGS&ISO
Outer Dimensions:
40.5*16*7mm
Digit Height:
10.16mm(0.4inch)
Polarity:
Common Anode
Segment/face Color:
White Diffused Epoxy Grey Face
LED Color:
Pure Green
Wavelength:
515-525nm
Luminous Intensity:
120-140mcd
Forward Voltage:
2.8-3.3V
Foreard Current:
12-15mA
Packaging Details:
EPE+CARTON
Supply Ability:
50000PCS/Day
Highlight:

outdoor 7 segment display

,

smd 7 segment led display

Product Description

Four Digit 7 segment Numeric LED Display 0.4 inch pure green for temperature control

Four Digit 7 segment Numeric LED Display 0.4 inch pure green for temperature control 0

Four Digit 7 segment Numeric LED Display 0.4 inch pure green for temperature control 1

KEY FEATURES/SPECIFICATIONS :

  • 0.4-inch 4-digit 7 segment led displays

  • Character height: 0.4-inch (10.16mm)

  • Outer dimensions: 40.5 x 16 x 7 mm

  • Polarity:Common anode

  • Made with white segments grey surface

  • Pure Green

  • Wavelength: 515-525nm

  • Luminous intensity: 120-140mcd/led

  • Forward voltage: 2.8-3.3V/led

  • Recommanded forward current: 12-15mA/led

  • Emitting color : Available in red,blue,green,amber, orange, white

  • Four Digit 7 segment Numeric LED Display 0.4 inch pure green for temperature control 2

  • Four Digit 7 segment Numeric LED Display 0.4 inch pure green for temperature control 3Four Digit 7 segment Numeric LED Display 0.4 inch pure green for temperature control 4

  • Four Digit 7 segment Numeric LED Display 0.4 inch pure green for temperature control 5

  • High luminous intensity and reliability

  • High efficiency

  • Low power consumption

  • Extremely low current

  • Luminous evenly distributed on each segment

  • Stable performance

  • Long lifespan

  • Easy assembly

  • IC Compatible

  • Meet RoHS Compliant

  • APPLICATION:

  • Widely used in set-top boxes, home appliances and instrument panels, digital indicators and so on.
