Multicolour Triple Digit 7 Segment LED Display For Refrigerator with 90 degree pin bending

name

Multicolour Triple Digit 7 Segment LED Display For Refrigerator with 90 degree pin bending

Brand Name: LIGHTBO
Model Number: LB3050SCWYR-S
MOQ: 1000PCS
Price: Negotiable
Payment Terms: TT in advance& Western Union
Supply Ability: 50000PCS/Day
Detail Information
Product Description
Detail Information
Place of Origin:
Shenzhen,China
Certification:
RoHS&SGS&ISO
Dimenisons:
38.5*19*8MM
Digit Height:
12.7mm (0.5inch)
LED Color:
White/Red/Yellow
Segment/Face Color:
Yellow Segments Black Surface
Polarity:
Common Anode
Usage:
Refrigerator Control
Packaging Details:
EPE+CARTON
Supply Ability:
50000PCS/Day
Highlight:

Refrigerator 7 Segment LED Display

,

90 Degree Pin Bending LED Display

,

Triple Digit LED Display

Product Description

Custom design common anode ultra bright blue triple digit 7 Segment LED Display for Refrigerator












  • Triple-Digit 7 segment led display
  •
  • Package dimension: 38.5 x 19 x 8 mm
  •
  • Character height: 12.7mm (0.5 inch)
  •
  • Polarity: common anode
  •
  • Made with yellow segments black surface with film
  •
  • Colour: ultra  bright white /red/yellow
  •
  • Wavelength:462-465nm/630-635nm/585-590nm
  •
  • Luminous intensity: 100-120mcd/ 70-90mcd/70-80mcd
  •
  • Forward voltage: 2.8-3.3V/1.8-2.3V/1.8-2.3V
  •
  • Recommanded Forward current:10-15mA/LED
  •
  • Single Row pins  with 90 degre pin bending ,suitable for vertical assembly

Multicolour Triple Digit 7 Segment LED Display For Refrigerator with 90 degree pin bending 0



Specifications:



  1. Wide viewing angle;
  2. High limunous intensity and reliability;
  3. Low current operation ;
  4. Low power consumption;
  5. Fast heat dissipation;
  6. Stable performance;
  7. Continuous uniform segments;
  8. Small and light, easy monutingon the PCB or sockets;
  9. Various colours and character height available;
  10. Long lifespan;
  11. Meet RoHS.

Multicolour Triple Digit 7 Segment LED Display For Refrigerator with 90 degree pin bending 1



Applications: widley used for temperature controller,air conditioner controller,refrigerator controller, digital indicators and so on .
