35mcd Common Anode Custom LED Display For E Cigarette

35mcd Common Anode Custom LED Display For E Cigarette

Brand Name:	LIGHTBO
Model Number:	LB4122IRG1B
MOQ:	1000PCS
Price:	Negotiation
Payment Terms:	TT in advance& Western Union
Supply Ability:	50000PCS/Day

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

RoHS&SGS&ISO

Outer Dimension:

41*22mm

Emitting Colour:

Ultra Bright Red，Green

Polarity:

Common Anode

Lifespan:

100000hrs

Usage:

Indoor/Outdoor

Application:

E-Cigarette

Packaging Details:

EPE +CARTON

Supply Ability:

50000PCS/Day

Highlight:

Common Anode Custom LED Display

35mcd Custom LED Display

E Cigarette Seven Segment Display

Product Description

Custom LED Display Custom Patterm Red Pure Green Color For E-Cigarette

Features:

Outer dimensions:14*22mm
Emitting color : ultra bright red and Green
Polarity: Common Anode

Advantages:

High-luminous intensity output
High-efficiency
Low-power consumption
Extremely low-current
Luminous evenly distributed on each segment
Emitting colors: various colors avaioaboe

Code:Ultra Bright Red

Parameter	Symbol	Condition	Min	Typ	Max	Unit
Forward Voltage	Vf	If=20mA	1.8		2.5	V
Reverse Voltage	Vr	Ir=10uA	5			V
Luminous Intensty	Iv	If=20mA	25		35	mcd
Spectrum With Of Half Value	△λ	If=20mA		20		nm
Wavelength	Dλ	If=20mA	625		635	nm

Absolute Maximum Ratings(Ta=25℃)

Parameter	Symbol	Ratings	Unit
Forward Current(per dice)	Ipm	20	mA
Reverse Voltage(per dice)	Vr	5	V
Power Dissipation(per dice)	Pm	80	mW
Operating Temperature Range	Topr	-40～+120	℃
Storage Temperature Range	Tstg	-40～+120	℃
Solder Temperature(3 sec)	Th	260	℃

LED working lifetime 100,000hrs

Absolute Maximum Rating at Ta=25℃

show:

35mcd Common Anode Custom LED Display For E Cigarette 0

Shipping:

Production:

FAQ:

1.Is your parts new ?

Answer: Yes, our parts could accept any kinds of testing, if there is any quality problem we will take responsibility.

2.What is your warranty?

Answer: Within one year after package have been received.

3.How to pay the order?

Answer: We could accept TT, Escrow, Paypal. After the order have been confirmed the invoice will be sent for reference. Then make payment as the way you like, as soon as the payment have been confirmed, we will arrange shipment.

4.Quality problems

Answer: If there is any quality problem or question, we could offer technical support or return service.

5.What is your lead time?

Answer: about 15-20 days ; For in-stock products. Lead time is about 5-7days after payment have been confirmed.

6. May I have a sample for testing?

Answer: Yes, only to pay shipping cost, free samples would be sent for testing.
